Product Details
Ricoh Gen5 Head (Mimaki TS500/TX500 MP-M014140) Description
This Gen5 (MH5420/5440) N221345D Printhead Assy Type-D is suitable for Mimaki TS500-1800 & TX500-1800 series printers. This is the original Mimaki part (number MP-M022653, replacing M014140).
Our printhead has a serial number. The printhead is required to be installed by professional personnel. All our printheads are high-precision commodities and brand new; any improper operation or substandard supporting products will damage the printheads. So, after receiving the goods, please first confirm the print head model and specifications. If there are any problems, please contact our sales staff as soon as possible. Any problem after the print heads are installed and used will be non-refundable.
Ricoh Gen5 Head (Mimaki TS500/TX500 MP-M014140) Specifications
| Nozzle number | 4*320 |
| Nozzle spacing | 0.1693mm |
| Nozzle density | Up to 600npi |
| Native drop volume | 7 pl |
| Drop volume range | 7-35 pl |
| Drop velocity | 7 m/s |
| Jetting frequency | Up to 60 kHz |
| Dimensions | 89*25*69mm (excluding cables) |
